Product Overview
When vibration monitoring in rotating machinery demands reliable, high-temperature performance, the Bently Nevada 330707-00-62-50-11-00 3300 XL 11 mm Proximity Probes delivers precision and durability. This probe is engineered for gap measurement and shaft vibration monitoring in harsh industrial environments. Its armored construction and FluidLoc cable protect against mechanical wear and process fluids, ensuring long service life.
Technical Specifications
| Specification |
Value |
| Probe Tip Material |
Polyphenylene sulfide (PPS) |
| Probe Case Material |
AISI 304 stainless steel (SST) |
| Probe Cable |
75 Ω triaxial, FEP insulated; lengths 1, 5, 9 m |
| Total Probe Length (this model) |
5.0 meters (16.4 feet) |
| Unthreaded Length |
0 in (00 option) |
| Overall Case Length |
6.2 in (62 option) |
| Connector Type |
Miniature coaxial ClickLoc with connector protector, FluidLoc cable (11 option) |
| Agency Approval |
Not required (00 option) |
| Operating & Storage Temperature |
-52°C to +177°C (-62°F to +351°F) |
| Probe DC Resistance (5.0 m) |
7.2 ± 0.8 ohms (center to outer conductor) |
| Probe Case Thread |
1/2-20 UNF |
| Max Thread Engagement |
0.750 in |
| Recommended Case Torque |
15.2 N•m (133 in•lb) |
| Maximum Case Torque |
45.2 N•m (400 in•lb) |
| Connector-to-connector Torque (max) |
0.565 N•m (5 in•lb) |
| Minimum Bend Radius |
25.4 mm (1.0 in) |
| Shipping Weight |
0.17 kg |
Industry Applications
The Bently Nevada 330707-00-62-50-11-00 3300 XL 11 mm Proximity Probes is widely used in turbomachinery, compressors, and large pumps for real-time shaft vibration and position monitoring. Its PPS tip and stainless steel case withstand corrosive atmospheres and high temperatures found in oil & gas refineries and power generation. The 5-meter cable and ClickLoc connector simplify installation in tight cable trays.
Installation & Setup Guidance
Mount the Bently Nevada 330707-00-62-50-11-00 probe in a 1/2-20 UNF tapped hole. Ensure thread engagement does not exceed 0.750 in to avoid binding. Apply the recommended 15.2 N•m torque to the case; never exceed 45.2 N•m. For the ClickLoc connector, use only finger-tight torque (max 0.565 N•m) to prevent connector damage. Maintain a minimum bend radius of 25.4 mm for the cable to avoid internal strain. The probe must be paired with a compatible 5-meter Proximitor sensor only.
Maintenance & Reliability
Routine inspection of the probe cable and connector for cuts or corrosion extends service life. Avoid exposing the probe to temperatures below -34°C (-30°F), as premature pressure seal failure may occur. The Viton O-ring seals the probe tip from the case; verify seal integrity during each maintenance cycle. The armored FluidLoc cable reduces wear from vibration, aligning with a failure-prevention strategy.
Selection Guide & Purchasing Advice
Before ordering, confirm that your system requires a 5-meter total probe length and a miniature ClickLoc connector. The 330707-00-62-50-11-00 is designed for use with the 5-meter Proximitor sensor only; do not mix cable lengths. For compatible mounting hardware and extension cables, contact UBEST Automation (ubest101) for a tailored solution.
