Product Overview
The Bently Nevada 200151-40-03-02 is a precision-engineered accelerometer interface cable designed for reliable vibration monitoring in industrial environments. This 4.0-meter cable features connectors on both ends, ensuring a secure and straightforward connection between accelerometers and monitoring systems. With its armored blue jacket and nylon coupling nuts, the 200151-40-03-02 delivers durability and flexibility for demanding applications.
Part of the Bently Nevada 200151 series, this cable is built to maintain signal integrity while withstanding harsh conditions. Whether you are upgrading existing machinery or installing new monitoring points, the 200151-40-03-02 provides the dependable link your system needs.
Technical Specifications
The following table details the key specifications of the Bently Nevada 200151-40-03-02. These values are directly from the manufacturer and define the cable's performance and physical characteristics.
| Specification |
Value |
| Model |
200151 - Accelerometer Interface Standard Cable |
| Cable Length |
4.0 meters (option -40) |
| Armor Option |
03 = Blue cable with armor |
| Coupling Nut |
02 = Nylon coupling nut |
| Minimum Bend Radius |
63.5 mm (2.5 in) |
| Operating Temperature Range |
-20 °C to +100 °C (-4 °F to +212 °F) |
| Construction |
4-conductor, 22 AWG with braided shield and drain wire (85% coverage, minimum), PVC outer jacket, nickel-plated coupling nuts |
| Seal |
Connectors provide IP67 seal; molded to cable; DC4 electrical insulating compound added for moisture protection |
| Temperature Range (DC4 compound) |
-55 °C to +121 °C (-67 °F to +250 °F) |
| Cure Time (DC4 compound) |
24 hours |
Key Features & Benefits
-
Robust Construction: The 4-conductor, 22 AWG design with braided shield (85% coverage) and drain wire minimizes electromagnetic interference, ensuring accurate signal transmission.
-
IP67 Sealing: Molded connectors with IP67 seal protect against dust and water ingress, making the 200151-40-03-02 suitable for wet or dusty environments.
-
Thermal Resilience: With an operating range of -20 °C to +100 °C, this cable performs reliably in extreme temperatures, while the DC4 compound extends resilience to -55 °C to +121 °C.
-
Flexibility: The 63.5 mm minimum bend radius allows installation in tight spaces without damaging the cable, provided it is not flexed below -20 °C.
-
Armored Protection: The blue armor option (03) adds an extra layer of defense against mechanical wear and abrasion.
Industry Applications
The Bently Nevada 200151-40-03-02 is ideal for vibration monitoring in rotating machinery such as pumps, motors, fans, and compressors. Use it to connect accelerometers to monitoring systems in:
-
Manufacturing Plants: Monitor production equipment to detect early signs of bearing wear or imbalance, reducing unplanned downtime.
-
Power Generation: Ensure reliable connectivity in turbines and generators where temperature fluctuations are common.
-
Oil & Gas Facilities: With IP67 sealing, the cable withstands harsh outdoor and washdown environments.
Installation & Setup Guidance
Follow these best practices to ensure optimal performance:
-
Bend Radius: Maintain a bend radius greater than 63.5 mm during installation. Avoid flexing the cable at temperatures below -20 °C to prevent damage.
-
Connector Handling: Align connectors carefully before tightening the nylon coupling nuts. Do not overtighten, as this may damage threads.
-
Cable Routing: Secure the cable along its path to prevent strain on connectors. Use cable ties or clamps every 30 cm.
-
Environmental Protection: Although IP67 rated, avoid prolonged submersion. If exposed to chemicals, verify compatibility with the PVC jacket.
Maintenance & Reliability
To maximize service life, inspect the 200151-40-03-02 periodically for signs of wear, cuts, or connector damage. Check coupling nuts for tightness and ensure the cable is not stressed at connection points. The armored jacket protects against abrasion, but routine visual checks help catch issues early. When replacing, always use the same model to maintain system consistency.
Selection Guide & Purchasing Advice
Before ordering, confirm your required cable length and connector types. The 200151-40-03-02 specifies 4.0 meters, armored blue jacket, and nylon coupling nuts. Verify that your accelerometer and monitoring system are compatible with this cable's 4-conductor, 22 AWG configuration. PLC Source PRO offers genuine Bently Nevada parts with reliable availability, ensuring you get the exact component your system needs.
