Product Introduction
When upgrading legacy variable frequency drives in industrial automation systems, the Allen-Bradley 22F-V6P0N103 offers a modern, compact solution. Part of the Rockwell Automation PowerFlex 4M series, this adjustable frequency drive controls speed and torque of variable-speed motors in PLC-controlled environments. Its small footprint and DIN rail mounting simplify integration into existing panels.
Technical Specifications Breakdown
The Allen-Bradley 22F-V6P0N103 is designed for light-duty applications. Key specifications include:
-
Input Power: 120 Volts AC, single-phase
-
Rated Amperage: 6 Amps
-
Rated Power: 1.1 kW (1.5 HP)
-
Enclosure Type: Open-IP20 (NEMA/UL open type)
-
Filter: Without CE compliant filter
These parameters make the 22F-V6P0N103 suitable for small conveyors, fans, and pumps where precise speed regulation via Volts per Hertz control is needed.
Industry Applications
The Allen-Bradley 22F-V6P0N103 excels in packaging machinery, material handling, and automated assembly lines. For example, in a conveyor system requiring gentle start/stop, the drive’s relay pre-charge limits inrush current, protecting belts and motors. Its adjustable PWM frequency ensures quiet operation in noise-sensitive environments like laboratories or clean rooms.
Installation & Setup Guidance
Mounting the Allen-Bradley 22F-V6P0N103 is straightforward. It supports both DIN rail and panel mounting. For optimal thermal performance, allow minimal clearance at 50 °C ambient; zero stacking is possible below 40 °C to save panel space. The integral keypad with four-digit display and ten LED indicators simplifies programming. Basic parameters are stored in the Basic Program Group for rapid configuration. For multi-drop networks, use the built-in RS-485/DSI communications.
Selection Guide & Purchasing Advice
Before purchasing the Allen-Bradley 22F-V6P0N103, verify that your system provides 120 VAC, single-phase input and that the motor rating does not exceed 1.1 kW. If CE compliance is required, note this model ships without a CE filter; order separately if needed. For wireless programming, consider a DSI Wireless Interface Module (WIM). For reliable sourcing, PLC Source PRO stocks genuine Allen-Bradley 22F-V6P0N103 drives with fast shipping.
