Product Overview
When variable speed control is essential for optimizing motor performance and energy efficiency, the Allen-Bradley 22F-V2P5N103 PowerFlex 4M adjustable frequency AC drive offers a reliable solution. This compact drive operates from a 100-120VAC, single-phase input and provides a 0-230VAC, three-phase output at 2.5 A and 0.4 kW (0.5 HP). Its integral RS485 communication port allows seamless integration into industrial networks.
Technical Specifications
The following table lists key specifications of the 22F-V2P5N103:
| Parameter |
Value |
| Input Voltage |
100-120VAC |
| Input Phase |
1-Phase |
| Input Current |
9.0 A |
| Output Voltage |
0-460VAC |
| Output Phase |
3-Phase |
| Output Current |
2.5 A |
| Output Power |
0.4 kW (0.5 HP) |
| Discrete Inputs |
Five (5) Sink/Source |
| Discrete Outputs |
One (1) Form C Contacts |
| Analog Input |
One (1) 0-10VDC or 0-20mA |
| Enclosure Rating |
IP20 / NEMA UL Open Type |
| Frame Size |
A |
| Control Method |
Volts per Hertz |
| Built‑in Communication |
RS485 |
| Optional Protocols |
BACnet, LonWorks, Profibus, Ethernet, DeviceNet, ControlNet |
Real‑World Applications
The 22F-V2P5N103 is ideal for applications requiring precise speed control of AC motors in a compact footprint. Common uses include:
- Conveyor systems in material handling where variable speed reduces wear and energy consumption.
- Fan and pump drives in HVAC and water treatment, benefiting from the drive’s ability to match motor speed to demand.
- Packaging machinery where space constraints demand a small‑form‑factor drive with robust performance.
By choosing the Allen-Bradley 22F-V2P5N103, operators achieve higher system efficiency and lower total cost of ownership over the equipment lifespan.
Compatibility and Integration
The 22F-V2P5N103 supports communication via its integral RS485 port using DSI protocol. It can be daisy‑chained with up to 31 drives for remote monitoring and control. Additionally, optional communication modules enable integration with BACnet, LonWorks, Profibus, Ethernet, DeviceNet, and ControlNet networks. This flexibility allows the drive to fit into existing automation architectures from Rockwell Automation and other major platforms.
Selection Guide and Purchasing Advice
Before purchasing, verify that your application’s input power matches the drive’s requirements: 100-120VAC single‑phase. Confirm that the motor horsepower rating (0.5 HP) and output current (2.5 A) are sufficient for your load. The compact frame A size and panel‑mount design simplify installation in tight spaces. For a reliable source of genuine Allen-Bradley 22F-V2P5N103 drives, consider ordering from PLC Source PRO, a trusted supplier of industrial automation spares.
