Product Overview
The Allen-Bradley 22F-RF010-AL PowerFlex EMC Filter Kit is an L-type radio frequency (RF) filter designed to suppress electromagnetic interference in variable frequency drive applications. Part of the PowerFlex family, this line filter kit handles 1-phase systems with 100-120/200-240V AC at 10A and supports long cable lengths. By attenuating conducted and radiated emissions, the 22F-RF010-AL ensures compliance with EMC standards and improves system reliability.
Technical Specifications
-
Filter Type: L-type RF filter
-
Rating: 1-Phase, 100-120/200-240V AC @ 10A
-
Class: Radio frequency (RF) filters
-
Cable Length: Supports long cable runs
These specifications make the 22F-RF010-AL suitable for installations where motor cables exceed standard lengths, maintaining signal integrity and reducing common-mode noise.
Industry Applications
The 22F-RF010-AL is ideal for environments with sensitive electronics, such as conveyor systems, pumps, and fans. In manufacturing plants, EMI from drives can disrupt nearby sensors and controllers. The Allen-Bradley 22F-RF010-AL filter mitigates these issues, allowing drives to operate near critical equipment without interference. For example, in a packaging line with long cable runs, this filter prevents false triggers and downtime.
Installation Guidance
Mount the Allen-Bradley 22F-RF010-AL close to the PowerFlex drive input. Ensure proper grounding per manufacturer guidelines. For long cable applications, place the filter as near the drive as possible to maximize suppression of high-frequency noise. Follow torque specifications for terminal connections to maintain reliable operation.
Selection Guide
When selecting the 22F-RF010-AL, verify your drive model and cable length requirements. This kit is designed for single-phase input at either 100-120V or 200-240V AC, 10A. For three-phase or higher current applications, choose a different filter from the RF010 series. PLC Source PRO offers genuine Allen-Bradley 22F-RF010-AL filters with fast shipping.
