Product Overview
Part of the reliable PowerFlex 40P family, the Allen-Bradley 22D-D010F104 is a compact AC drive designed to replace older drive models with enhanced safety and control features. This industrial automation module delivers precise speed control for applications such as automotive assembly, packaging, and material handling. With its Category 3 Safe-off functionality, it reduces the need for external safety components, simplifying system design and lowering costs.
Technical Specifications
| Parameter |
Value |
| Model Number |
22D-D010F104 |
| Product Line |
PowerFlex 40P |
| Input Voltage |
480 VAC, 3-Phase, 50-60 Hz |
| Output Current |
10.5 A |
| Power Rating |
5 HP (4.0 kW) |
| Enclosure |
IP20, NEMA Type Open, Flange Mount |
| Frame Size |
B |
| Dimensions (WxHxD) |
24.4 x 25 x 18.2 cm |
| Safety Feature |
Safe-off Category 3 |
| Control Method |
Sensorless Vector Control, Closed-Loop |
| Display |
HMI with Reset Only |
Industry Applications
The Allen-Bradley 22D-D010F104 is ideal for upgrading older drives in automotive production lines where precise speed control and safety are critical. In packaging machinery, its compact size and flange mount allow easy integration into tight spaces. The drive’s Autotune feature simplifies commissioning when replacing existing units, reducing downtime.
Installation Guide
When replacing an existing drive with the 22D-D010F104, verify that the input voltage and current ratings match your system. The flange mount is designed for panel installation; ensure adequate ventilation for the IP20 enclosure. The dimensions of 24.4 x 25 x 18.2 cm allow for straightforward retrofit in most control cabinets.
Selection Guide
Confirm that the Allen-Bradley 22D-D010F104’s 480 VAC input and 10.5 A output meet your motor requirements. For applications needing a CE-compliant filter, note that this unit does not include one. As a trusted supplier, PLC Source PRO offers this drive with fast shipping and dedicated support.
Additional Parameters
| Parameter |
Value |
| Brand |
Allen-Bradley 22D-D010F104 |
| Series |
PowerFlex 40P |
| Enclosure Type |
Open NEMA Type - Flange Mount (IP20) |
| Power Rating |
5 HP (4.0 kW) |
| Safety |
Safe-off Category 3 |
| Control Method |
Sensorless Vector Control, Closed-Loop |
