The Allen-Bradley 22C-D012H103 PowerFlex 400 adjustable frequency drive delivers significant energy savings and reduced maintenance costs for industrial fan and pump systems. Designed by Rockwell Automation, this variable frequency drive optimizes speed control for variable torque applications, lowering operating expenses and extending equipment life.
Technical Specifications
Based on product documentation, the Allen-Bradley 22C-D012H103 offers the following key parameters:
- Product Line: PowerFlex 400
- Drive Type: Fan & Pump
- Horsepower: 7.5 HP (5.5 kW)
- Input Voltage: 480 Volts AC, 3-Phase
- Amperage: 12 Amps
- Frequency: 50 to 60 Hertz
- Enclosure: IP30, UL-NEMA Type Open
- Control: PID with RS-485 communication
- Digital Inputs: 3 semi-programmable, 4 fully programmable
- Analog I/O: 2
- Relays: 2 programmable
Contact PLC Source PRO for detailed datasheet and additional specifications.
Industry Applications
The Allen-Bradley 22C-D012H103 excels in commercial and industrial environments requiring precise speed control for fans and pumps. Typical applications include HVAC systems, water treatment plants, and process ventilation. By matching motor speed to load demand, this drive cuts energy consumption and reduces mechanical wear, translating into lower total cost of ownership.
Installation & Setup
This panel-mounted drive features a fixed terminal block connection for straightforward wiring. The RS-485 port ensures reliable operation in electrically noisy environments. Install the Allen-Bradley 22C-D012H103 in a clean, dry location with adequate ventilation. The IP30 enclosure protects against solid objects larger than 12 mm. Use shielded cables for the RS-485 network to maintain signal integrity.
Selection Guide & Purchasing Advice
Before purchasing the Allen-Bradley 22C-D012H103, verify that your motor's voltage and current ratings match the drive specifications. For assistance with system integration or to place an order, contact PLC Source PRO. We stock a wide range of industrial automation parts to support your operations.
