Product Overview
The Allen-Bradley 20F1AND361AN0NNNNN is a high-performance AC drive from the PowerFlex 753 series, engineered for demanding industrial motor control applications. This air-cooled drive handles input voltages up to 480 V AC in a 3-phase configuration and features a DC bus operating around 650 V DC, making it suitable for high-power environments.
With an output current rating of 361 A and a power rating of 300 HP for normal duty (ND) and 250 HP for heavy duty (HD), the 20F1AND361AN0NNNNN delivers robust performance for a wide range of industrial processes.
Technical Specifications
Below are the key technical specifications for the Allen-Bradley 20F1AND361AN0NNNNN:
| Specification |
Value |
| Manufacturer |
Allen Bradley |
| Product Type |
AC Drive |
| Product Line |
PowerFlex 753 |
| Part Number |
20F1AND361AN0NNNNN |
| UPC |
884951167988 |
| Weight |
150.00 lbs (68.04 kg) |
| Input Voltage |
480 V AC, 3-phase |
| DC Bus |
~650 V DC link |
| Output Current |
361 A |
| Power Rating |
300 HP ND / 250 HP HD (~220 kW) |
| Output Phase |
3-phase |
| Cooling |
Air cooled |
| Enclosure |
Open style, IP20/IP00 |
| Filtering |
Built-in EMC, jumper removed |
| Input Design |
AC with precharge circuit |
| Braking |
None |
| I/O |
Integrated control I/O |
| Expansion |
3 option slots |
| Operator Interface |
No HIM |
Key Features & Benefits
The Allen-Bradley 20F1AND361AN0NNNNN offers several advantages for industrial operations:
-
High Power Output: Suitable for heavy-duty applications requiring up to 300 HP, ensuring reliable performance under load.
-
Robust Input Design: With a precharge circuit, the drive ensures smooth start-up and reduced stress on components.
-
Air-Cooled System: Efficient thermal management promotes longer service life and consistent operation.
-
Open-Style Enclosure (IP20/IP00): Facilitates easy access for maintenance and integration into existing panels.
-
Integrated Control I/O: Simplifies wiring and reduces external component requirements.
-
Expandable: Three option slots allow customization to meet specific application needs.
Industry Applications
The 20F1AND361AN0NNNNN is designed for a variety of industrial motor control tasks, including:
-
Conveyor Systems: Delivers precise speed control for material handling in manufacturing and distribution centers.
-
Pumps and Fans: Provides efficient variable-speed operation, reducing energy consumption in HVAC and process industries.
-
Machine Tools: Offers the torque and control needed for demanding metalworking and fabrication equipment.
In each scenario, the drive's high output current and robust design ensure reliable operation, minimizing downtime and maximizing productivity.
Installation & Setup Guidance
When installing the Allen-Bradley 20F1AND361AN0NNNNN, consider the following practical steps:
-
Mounting: Ensure the drive is mounted in a clean, dry location with adequate clearance for airflow. The open-style enclosure requires proper spacing for cooling.
-
Wiring: Follow the manufacturer's wiring diagram for input and output connections. Verify that the input voltage matches the 480 V AC, 3-phase rating.
-
Grounding: Properly ground the drive to prevent electrical noise and ensure safety.
-
Precharge Circuit: The precharge circuit is integrated; ensure it is not bypassed to maintain smooth start-up.
Maintenance & Reliability
Regular maintenance of the 20F1AND361AN0NNNNN helps maximize its lifespan and avoid unexpected failures. Key practices include:
-
Inspection Intervals: Periodically check for dust accumulation on cooling surfaces and clean as needed to maintain airflow.
-
Connection Checks: Inspect all power and control wiring for tightness and signs of wear.
-
Environmental Monitoring: Keep the drive within specified temperature and humidity ranges to prevent component stress.
By investing in routine care, you reduce the total cost of ownership and ensure consistent performance over the long term.
Compatibility & Integration
The PowerFlex 753 series is designed for easy integration into existing automation systems. While the 20F1AND361AN0NNNNN includes integrated control I/O, its three expansion slots allow for additional communication modules or I/O cards to suit your network requirements. This flexibility enables seamless connection to PLCs and other control systems commonly used in industrial environments.
Selection Guide & Purchasing Advice
Before purchasing the Allen-Bradley 20F1AND361AN0NNNNN, verify that your application's voltage, current, and power requirements match the specifications provided. Consider any optional modules you may need for communication or additional I/O, and ensure your enclosure meets the IP20/IP00 protection rating.
For reliable sourcing and competitive pricing, PLC Source PRO offers this drive along with a wide range of industrial automation parts. Visit www.plcsourcepro.com to explore inventory and place your order.
