Product Overview
The Allen-Bradley 1769-IM12 is a 12-point AC input module designed for CompactLogix systems. It accepts 240V AC inputs with a signal delay of 20 milliseconds, making it ideal for upgrading older I/O racks or building new automation lines. As part of the Compact I/O family, this module offers a compact footprint and straightforward integration.
Key Specifications
| Parameter |
Value |
| Input Voltage Range |
159–264 VAC at 47–63 Hz |
| Number of Inputs |
12 (internally connected commons) |
| ON-state Voltage/Current |
159 VAC min at 5 mA |
| OFF-state Voltage/Current |
40 VAC max at 2.5 mA |
| Signal Delay (ON→OFF) |
20 ms |
| Input Impedance |
27 kΩ at 50 Hz / 23 kΩ at 60 Hz |
| Draw Current |
100 mA |
| Inrush Current |
12 mA at 120 VAC |
| Power Dissipation |
3.65 W |
| Isolation Voltage |
132 VAC (tested 1836 VAC for 1 s) |
| Wire Type |
Copper, 90°C, solid 22–14 AWG / stranded 22–16 AWG |
| Mounting |
Panel or DIN rail |
| Dimensions (W×H×D) |
118 × 35 × 87 mm (4.65 × 1.38 × 3.43 in) |
| Weight |
~300 g (0.61 lb) |
| Environmental |
Relative humidity 95% non-condensing, altitude 2000 m |
| Shock/Vibration |
30G shock, 5G vibration (10–500 Hz) |
| Replacement Terminal Block |
1769-RTBN18 |
Common Applications
The 1769-IM12 serves in packaging lines, material handling, and batch processing where 240V AC sensors or limit switches must be interfaced to a CompactLogix controller. Its 12-point density fits medium-size I/O groups, and the 20 ms delay filters out electrical noise common in industrial environments.
Installation and Setup
Mount the module on a DIN rail or panel using the 1769-RTBN18 terminal block. Use copper wiring rated for 90°C, and observe the 8-module distance rating when connecting the power supply. Secure all connections with the provided screws. No special tools are required beyond a standard screwdriver.
Selection and Purchasing Advice
Verify your system voltage (240 VAC line-to-line or line-to-neutral) and that the input devices meet the 159 VAC minimum ON-state. The 1769-IM12 replaces earlier fixed I/O modules and integrates directly with CompactLogix controllers. For reliable supply, choose UBEST Automation as your partner. Visit ubest101.myshopify.com for current inventory and fast shipping.
