Product Overview
When speed sensor failure leads to unplanned downtime, the AI-TEK 70085-3030-113 provides reliable rotational speed measurement for critical machinery. This industrial automation module functions as a robust speed sensor with a 5/8-18 thread and 1/2 NPT conduit thread, ensuring secure installation in harsh environments. The AI-TEK 70085-3030-113 delivers a guaranteed output voltage of 13.4 V peak-to-peak, making it suitable for various monitoring systems.
Technical Specifications
The following table lists the key specifications of the AI-TEK 70085-3030-113:
| Parameter |
Value |
| Thread Size |
5/8-18 |
| Output Guarantee Voltage (P-P) |
13.4 V |
| Termination |
Cable |
| Thread Length |
4 in |
| Sensor Length |
5.25 in |
| Temperature Rating |
-65 to 95 °C |
| Cable Length |
3 m |
| Conduit Thread |
1/2 NPT |
| Agency Approval |
None |
These specifications ensure compatibility with standard industrial installations. The 13.4 V P-P output provides strong signal integrity, while the wide temperature range allows operation in extreme conditions.
Industry Applications
The AI-TEK 70085-3030-113 excels in applications requiring precise speed feedback, such as turbine overspeed protection, conveyor belt speed control, and pump monitoring. In replacement scenarios, this sensor directly upgrades older units with similar thread patterns, improving reliability and reducing maintenance costs.
Installation and Setup
Install the sensor by threading it into a 5/8-18 tapped hole. Use the 1/2 NPT conduit thread for cable entry. Ensure the sensor tip is within the specified gap from the target gear tooth. Route the 3-meter cable away from high-interference sources. Verify the output voltage with an oscilloscope before finalizing placement.
Maintenance and Reliability
The sensor's rugged design withstands temperatures from -65 to 95 °C. Periodically inspect the cable for wear and ensure the mounting remains tight. No agency approvals imply use in non-hazardous locations. Regular checks extend service life and prevent unexpected failures.
Selection Guide
Before purchasing, confirm your application requires a 5/8-18 thread and 1/2 NPT conduit connection. The 3-meter cable length suits most machinery layouts. For replacement needs, verify the output voltage compatibility. PLC Source PRO offers the authentic AI-TEK 70085-3030-113 to ensure reliable operation. Contact ubest101 for further inquiries.
