Product Introduction
In extreme temperature environments, the AI-TEK 70085-1010-227 speed sensor delivers reliable rotational speed measurement. This rugged sensor handles -73 to 232°C, making it ideal for turbines, compressors, and other high-heat applications. Part of AI-TEK's trusted industrial sensor family, the 70085-1010-227 ensures accurate monitoring in harsh conditions.
Technical Specifications Breakdown
The AI-TEK 70085-1010-227 offers precise output characteristics:
-
Output Voltage (Standard): 4.7 V (P-P) – ensures strong signal transmission.
-
Output Voltage (Guarantee Point): 0.4 V (P-P) – minimum guaranteed signal.
-
DC Resistance: 125 ohms max. – low resistance for efficient operation.
-
Typical Inductance: 5-12 mH ref. – suitable for inductive proximity sensing.
-
Operating Temperature: -73 to 232°C – exceptional thermal range.
-
Thread Size: 1/4-40 – standard mounting interface.
Industry Applications
The AI-TEK 70085-1010-227 excels in demanding sectors. In power generation, it monitors turbine shaft speed under high heat. In petrochemical plants, it tracks compressor RPM in volatile environments. Its wide temperature range reduces downtime, providing long-term ROI by avoiding frequent replacements.
Installation & Setup Guidance
Mount the AI-TEK 70085-1010-227 using the 1/4-40 thread. The sensor length is 2 inches, thread length 1.687 inches. Connect via 8-inch lead wires, with white lead positive. For cable extension, use the 60-inch optional cable. Ensure the sensor tip aligns with the target for consistent readings.
Maintenance & Reliability
The AI-TEK 70085-1010-227 requires minimal upkeep due to its all-metal construction and no moving parts. Regularly inspect lead wires for damage in high-vibration areas. The -73 to 232°C rating means it withstands thermal cycling without calibration drift, lowering total cost of ownership.
Selection Guide & Purchasing Advice
Before purchasing, verify your application's thread size (1/4-40) and temperature range. The AI-TEK 70085-1010-227 outputs 4.7 V P-P standard, suitable for most PLC or counter inputs. For reliable supply, order from ubest101 (the official store) – a trusted source for industrial automation spares.
