Product Introduction
The AI-TEK 70085-1010-086 Speed Sensor is a robust industrial automation module designed for accurate rotational speed measurement in harsh environments. With a threaded 3/8-24 mounting and wire termination, this sensor delivers reliable performance across a wide temperature range. The 70085-1010-086 is engineered for applications that demand consistent output and long service life, minimizing costly downtime and maintenance.
Technical Specifications
Though specific datasheets may vary, the key parameters for the AI-TEK 70085-1010-086 include:
-
Output Voltage (Standard): 55 V P-P
-
Output Voltage (Guarantee Point): 4.2 V P-P
-
Thread Size: 3/8-24
-
Thread Length: 0.812 in
-
Sensor Length: 1.252 in
-
Operating Temperature: -55 to +107°C
-
DC Resistance: 960 ohms max
-
Typical Inductance: 125 mH ref.
-
Net Weight: 2 oz. max
-
Lead Length: 18 in (45.7 cm) for -086 variant
-
Output Polarity: White lead positive
For detailed technical specifications not listed here, please contact PLC Source PRO directly.
Industry Applications
The AI-TEK 70085-1010-086 Speed Sensor is ideal for monitoring rotating machinery in industries such as oil and gas, power generation, and manufacturing. Its high output voltage and wide temperature tolerance make it suitable for turbine speed monitoring, conveyor belt tracking, and motor shaft measurement. By providing precise speed data, the 70085-1010-086 helps prevent overspeed conditions and improves overall equipment efficiency, delivering a strong return on investment through reduced unplanned downtime.
Installation & Setup Guidance
Mount the AI-TEK 70085-1010-086 using the 3/8-24 threaded body, ensuring proper alignment with the target gear or shaft. The wire termination allows flexible connection to control systems. Maintain an air gap of 0.005 to 0.060 inches between the sensor tip and the rotating ferrous object for optimal signal strength. Secure the wires to avoid stress on the 18-inch leads. For best results, follow the manufacturer's guidelines for mounting distance and orientation.
Maintenance & Reliability
The AI-TEK 70085-1010-086 is built for long-term reliability with no moving parts, requiring minimal maintenance. Regularly inspect the sensor for physical damage, dirt accumulation, and secure mounting. The robust construction withstands temperatures from -55°C to +107°C, making it suitable for demanding environments. Proper installation and periodic checks ensure the sensor maintains its guaranteed output of 4.2 V P-P at the specified air gap, extending service life and maximizing ROI.
Selection Guide & Purchasing Advice
When selecting the AI-TEK 70085-1010-086, verify that the thread size (3/8-24) matches your mounting requirements and that the lead length (18 inches for -086 variant) is sufficient for your wiring path. This sensor is a direct replacement for many existing speed sensors in industrial automation systems. For additional variants or custom lengths, contact PLC Source PRO (available through ubest101.myshopify.com) for assistance. Always ensure the sensor's output voltage and temperature ratings align with your application's demands.
