Product Introduction
When electromagnetic interference (EMI) threatens the reliable operation of your variable frequency drive, the Allen-Bradley 22F-RF6P0-AS EMC Filter Kit provides a robust solution. Designed specifically for PowerFlex 4M drives, this filter kit ensures compliance with EMC standards and prevents nuisance trips. The 22F-RF6P0-AS is a line filter kit that attenuates conducted noise on the input power line, protecting sensitive equipment and maintaining system integrity.
Technical Specifications
The Allen-Bradley 22F-RF6P0-AS offers the following key specifications from the manufacturer:
- Type: Line Filter Kit, 3-Phase
- Voltage Rating: 200-240V AC
- Current Rating: 6.0A
- Cable Length: Short Cable Length
- EMC Filter Type: S Type
- Compatible Drive: PowerFlex 4M, 0.4 to 1.5 kW at 480V AC, 50/60 Hz
Industry Applications
The Allen-Bradley 22F-RF6P0-AS is ideal for applications where PowerFlex 4M drives control motors in environments sensitive to electrical noise. Common use cases include packaging machinery, conveyor systems, and pump stations. By installing this EMC filter kit, you reduce the risk of drive communication errors and sensor misreads caused by conducted EMI. For example, in a packaging line with multiple drives, using the 22F-RF6P0-AS ensures that the drive's power input is clean, preventing intermittent faults that lead to downtime.
Installation Guide
Mount the Allen-Bradley 22F-RF6P0-AS filter kit close to the PowerFlex 4M drive input terminals. Use the provided short cable lengths to minimize radiated emissions. Ensure proper grounding according to the drive manual. The filter is designed for 3-phase 200-240V AC systems at 6A. Verify the drive's input voltage matches the filter rating before connection. For optimal EMC performance, keep the filter and drive wiring separate from control cables.
Selection Guide & Purchasing Advice
Before purchasing, confirm that your PowerFlex 4M drive operates within the 0.4 to 1.5 kW range at 480V AC. The Allen-Bradley 22F-RF6P0-AS is specifically for this drive series and voltage class. Also verify your input line voltage is 200-240V AC 3-phase. For additional support, contact PLC Source PRO for compatibility verification and stock availability. PLC Source PRO is a trusted supplier of industrial automation spares.
