Product Overview
The Allen-Bradley 22D-B5P0N104 PowerFlex 40P adjustable frequency drive delivers cost-effective motor control with high efficiency. With 1 HP (0.75 kW) output and 5.0 A at 240 VAC three-phase, this drive achieves 97.5% efficiency, reducing energy costs and improving ROI. Its robust design includes protective features that minimize downtime, making it a smart investment for industrial automation.
Key Technical Specifications
| Parameter |
Value |
| Brand |
Allen-Bradley |
| Part Number |
22D-B5P0N104 |
| Product Line |
PowerFlex 40P |
| Amperage |
5.0 A |
| Phase |
Three-Phase |
| Enclosure |
Open NEMA Type (Panel Mount IP20) |
| Input Power |
240 Volts AC |
| Horsepower |
1 HP |
| Filter |
No CE Compliant Filter |
| Type |
Standard |
| Frame Size |
B |
| UPC |
820919653995 |
The Allen-Bradley 22D-B5P0N104 also includes integrated protection against ground faults, electronic motor overload, and 6kV transients, enhancing system longevity.
Industry Applications
This drive excels in palletizers, smart conveyors, and drafting machines. For example, in conveyor systems, the 22D-B5P0N104 sensorless vector control maintains precise speed regulation, reducing product waste and improving throughput. The high efficiency translates directly to lower operating costs over the drive's lifespan.
Installation and Setup Guidance
Mount the Allen-Bradley 22D-B5P0N104 in a clean, dry area with proper airflow. Use the IP20 panel mount enclosure for indoor installations. The built-in display simplifies parameter changes, and the reset button quickly clears faults. Ensure the input voltage matches 240 VAC three-phase and that the drive is not exposed to volatile vapors.
Maintenance and Reliability
Regularly inspect the cooling fan and heat sink for dust buildup. The drive's 60 W estimated power dissipation means efficient heat management, but proper ventilation extends component life. The electronic motor overload protection reduces the need for external overload relays, lowering maintenance costs. With 97.5% efficiency, the 22D-B5P0N104 saves energy and reduces total cost of ownership.
Selection and Purchasing Advice
Before ordering, confirm your motor’s voltage and current requirements match the 22D-B5P0N104’s 240 VAC, 5.0 A rating. This drive does not include a CE compliant filter, so consider external filtering if needed for your application. For reliable supply of genuine Allen-Bradley parts, choose PLC Source PRO.
