Product Overview
The Allen-Bradley 1794-TB2 is a FLEX I/O terminal base unit engineered for reliable field wiring in industrial control systems. Part of the Allen-Bradley Flex I/O 1794 series, this terminal base unit provides a secure mounting and wiring interface between field devices and I/O modules. Its cage clamp termination ensures vibration-resistant connections, making it suitable for demanding environments.
Key Features & Benefits
-
Cage clamp termination for secure, maintenance-free wiring.
-
UL listed and CSA certified for global acceptance.
-
Flexible mounting – panel or DIN rail installation.
-
Three terminal rows (16, 18, and 2 terminals) accommodate various wiring configurations.
-
Robust operating range – handles up to 125V DC/AC and 10A.
Technical Specifications
| Specification |
Value |
| Manufacturer |
Rockwell Automation |
| Brand |
Allen-Bradley |
| Part Number |
1794-TB2 |
| Product Type |
Flex I/O Terminal Base Unit |
| Terminal Screw Torque |
0.56–0.79 Nm |
| Supply Voltage Range |
Max 125V DC/AC, 50/60Hz, 10A |
| Isolation Voltage |
125V Continuous |
| Voltage Rating |
24V DC/AC, 120V DC/AC |
| Wire Size |
0.21–1.3 mm² |
| Dimensions |
94 x 94 x 69 mm |
Installation & Mounting
The 1794-TB2 supports both panel and DIN rail mounting. For panel mounting, use the provided holes and secure with appropriate hardware. For DIN rail, snap the unit onto a standard 35mm rail. Ensure the terminal screw torque is within 0.56–0.79 Nm to avoid over-tightening. Use 24 to 16 AWG stranded copper wire with 3/64-inch insulation for connections.
Applications
This terminal base unit is ideal for discrete and analog I/O applications in manufacturing, process control, and material handling. It provides a robust wiring interface for sensors, actuators, and control signals. Its compact design fits easily into existing panels, making it a practical choice for system upgrades.
Maintenance & Reliability
With no moving parts, the 1794-TB2 requires minimal maintenance. Periodically inspect terminal connections for tightness and cleanliness. The unit operates reliably in temperatures from 0 to 55°C and withstands vibration up to 5g at 10–500Hz. Its open-type enclosure allows heat dissipation, but ensure adequate airflow in the panel.
Compatibility & Integration
The 1794-TB2 is designed for use with Allen-Bradley Flex I/O modules. It provides the physical interface for modules to connect to the Flexbus backplane. Verify module compatibility before ordering.
Ordering & Support
When purchasing, confirm your system’s voltage and wiring requirements. PLC Source PRO offers genuine Allen-Bradley components with fast worldwide shipping. Contact our team for availability and bulk pricing.
