Product Overview
The Allen-Bradley 1769-BA is a lithium battery module engineered for the CompactLogix series of programmable automation controllers. As an Industrial Automation Module, it ensures that volatile memory remains intact during power loss, safeguarding your user programs, configuration data, and critical process parameters.
Technical Specifications
The 1769-BA operates with a nominal output voltage of 3.0 VDC and a nominal capacity of 850mAh. Its physical dimensions are 0.58 inches in diameter by 1.04 inches in length, with a shipping weight of 2 lbs. and shipping dimensions of 8 x 8 x 5 inches. The module supports a continuous isolation voltage of 30 volts, an open enclosure design, and draws a backplane current of 1.4 amps at 24 volts. Power consumption is rated at 33.6 watts, with power dissipation of 7.5 watts. It is compatible with both Series A and Series B configurations.
| Parameter |
Value |
| Manufacturer |
Rockwell Automation |
| Brand |
Allen-Bradley |
| Part Number |
1769-BA |
| Product Line |
CompactLogix |
| Module Type |
Battery |
| Shipping Weight |
2 lbs. |
| Shipping Dimensions |
8 x 8 x 5 in. |
| Series |
A and B |
| Isolation Voltage |
30 Volts Continuous |
| Enclosure |
Open |
| Backplane Current |
1.4 Amps at 24 Volts |
| Power Consumption |
33.6 Watts |
| Power Dissipation |
7.5 Watts |
| Nominal Output Voltage |
3.0 VDC |
| Nominal Capacity |
850mAh |
| Dimensions (Battery Cell) |
0.58" diameter x 1.04" long |
Key Features & Benefits
- Preserves volatile memory in CompactLogix controllers during power interruptions.
- Compatible with multiple controllers, including 1769-L23-QBFC1B, 1769-L23E-QB1B, 1769-L23E-QBFC1B, 1769-L31, 1769-L32C, 1769-L35CR, 1769-L32E, and 1769-L35E.
- Meets dangerous goods regulations (US DOT 49CFR 173.185, IATA Packing Instructions 968 Section II, ADR 188, IMDG 188).
- Wire leads enable quick connection to controller circuitry.
- Open enclosure design promotes airflow and heat dissipation.
Applications
The 1769-BA is ideal for manufacturing plants, process control systems, and any facility relying on CompactLogix controllers for critical operations. It ensures that your programs and data remain safe during unexpected shutdowns, minimizing downtime and preventing costly reprogramming.
Installation & Replacement
To replace an existing 1769-BA, the controller must be actively powered to retain memory. Remove the old battery and insert the new one, ensuring correct orientation. The battery is used only when the controller is powered down; if non-volatile memory (SD or CompactFlash) is installed, the battery can be removed even when powered off. Always dispose of old batteries according to local regulations.
Maintenance & Storage
Store the 1769-BA in a cool, dry, well-ventilated area, away from direct sunlight, water, and heat sources. Avoid short-circuiting, disassembling, or incinerating the battery. When replacing multiple batteries, replace all at once. Monitor the BAT indicator; when it activates, replace the battery promptly to avoid data loss.
Compatibility & Integration
The 1769-BA is designed for use with the Allen-Bradley CompactLogix series, specifically the 1769-L2x and 1769-L3x controllers. It maintains volatile memory, ensuring seamless operation with your existing control system.
Selection Guide
When purchasing a replacement battery, verify that your controller model is listed as compatible. For bulk orders or OEM applications, ensure the battery meets your regulatory requirements. PLC Source PRO offers genuine Allen-Bradley 1769-BA modules with fast shipping and competitive pricing.
