Product Overview
The Allen-Bradley 150-FPP970B SMC Flex power pole is a single-phase, modularly designed power pole engineered for the SMC Flex Low-Voltage Soft Starter family. This replacement assembly supports 3-phase squirrel cage induction motors rated up to 970 Amps and 800 Horsepower. The 150-FPP970B belongs to Series B of the SMC Flex accessory line and includes two screws, connecting cables, and an instruction manual for straightforward installation.
Technical Specifications
Key parameters for the Allen-Bradley 150-FPP970B are listed below:
| Specification |
Value |
| Manufacturer |
Allen-Bradley |
| Category |
Drives |
| Product Line |
SMC-Flex |
| Part Number |
150-FPP970B |
| Weight |
20.00 lbs (9.07 kg) |
| Description |
SMC Flex Power Pole |
| Power Rating |
800 Horsepower |
| Line Input Voltage |
200 to 480 Volts AC |
| Current Rating |
970 Amps |
| Phase |
Single-Phase |
| Compatible Devices |
3-Phase Squirrel Cage Induction Motors |
Key Features & Benefits
The 150-FPP970B power pole is a modular replacement component that ensures minimal downtime during maintenance. Its single-phase design allows flexible wiring for single-phase applications while supporting the robust starting requirements of 3-phase motors. The included hardware and manual simplify the replacement process, reducing installation time and labor costs.
Industry Applications
This power pole is ideal for industries that rely on SMC Flex soft starters, such as:
- Pumping stations and water treatment facilities
- Conveyor systems in manufacturing plants
- HVAC and compressor applications
In each scenario, the 150-FPP970B delivers reliable power switching for motors up to 800 HP, ensuring smooth acceleration and extended equipment life.
Installation & Setup Guidance
Before installation, verify that the 150-FPP970B matches the voltage and current ratings of your SMC Flex controller. Disconnect all power sources and follow the provided instruction manual. Use the included screws and connecting cables to secure the power pole. Ensure proper torque and cable routing to prevent overheating.
Compatibility & Integration
The Allen-Bradley 150-FPP970B is specifically designed for the SMC Flex smart motor controller family. It integrates seamlessly with controllers configured for 3-phase squirrel cage induction motors. The DPI communication port on the controller remains fully functional, allowing easy setup and monitoring through the onboard keypad or network.
Selection Guide & Purchasing Advice
When ordering a replacement power pole, confirm your controller's series and current rating. The 150-FPP970B is rated for 970 Amps and 800 HP—using it with lower-rated controllers may cause compatibility issues. PLC Source PRO offers this genuine Allen-Bradley 150-FPP970B power pole with fast shipping and warranty support.
