Product Overview
The Allen-Bradley 150-F43NCD is a solid state controller from the SMC-Flex series, engineered to deliver precise motor starting and stopping while reducing mechanical stress and energy consumption. This Industrial Automation Module combines advanced diagnostics, programmability, and robust construction to support demanding three-phase applications. With an open enclosure and a controller rating of 43 A at 30 Hp (460V AC), the 150-F43NCD is designed for reliable performance in industrial environments.
Key Features & Benefits
-
Smart Motor Control: The 150-F43NCD provides nine start/stop modes and three slow-speed modes, offering flexible control for diverse applications.
-
Integrated Bypass: Reduces energy consumption and heat generation during continuous operation.
-
Built-in LCD & Keypad: Enables easy monitoring, parameter adjustment, and real-time diagnostics.
-
Comprehensive Protection: Includes jam and stall detection, plus automatic shutdown to prevent equipment damage.
-
Wide Input Range: Accepts 200-575V AC, 3-phase, 50/60 Hz input line, making it suitable for global installations.
Technical Specifications
| Specification |
Value |
| Manufacturer |
Allen-Bradley |
| Category |
Drives |
| Product Line |
SMC-Flex |
| Part Number |
150-F43NCD |
| UPC |
781180617492 |
| Weight |
20.00 lbs (9.07 kg) |
| Bulletin Number |
Solid State Controller |
| Enclosure Type |
Open |
| Controller Rating |
43 A, 30 Hp at 460V AC |
| Input Line Voltage |
200-575V AC, 3-phase, 50/60 Hz |
| Control Voltage |
100-240V AC (5-480 A units) |
| Rated Voltage |
500/575V AC |
Industry Applications
The 150-F43NCD excels in applications requiring controlled acceleration and deceleration. Common uses include:
-
Bandsaws: Minimizes starting peaks, stops the motor in two minutes, and provides jam/stall diagnostics.
-
Compressors: Reduces torque spikes and extends mechanical life.
-
Pumps: Standard pump control reduces water hammer and pressure surges.
-
Centrifuges: Smooth, controlled starts and stops protect product integrity.
By integrating the 150-F43NCD, facilities can achieve significant energy savings and lower maintenance costs, making it a cost-effective upgrade for aging motor starters.
Installation & Setup Guidance
Install the 150-F43NCD in a clean, dry location with adequate ventilation. The open enclosure requires mounting inside a suitable cabinet to meet IP ratings. Verify that the input line voltage matches the unit's rating (200-575V AC) and that the control voltage is within 100-240V AC. Use appropriately sized conductors for 43 A continuous current. Configure the controller using the built-in keypad and LCD, selecting the appropriate start/stop mode for your application. Always follow local electrical codes and safety regulations.
Maintenance & Reliability
Regular maintenance ensures long-term reliability. Periodically inspect the unit for dust accumulation, loose connections, and signs of overheating. Clean the enclosure and heatsink with dry compressed air. Verify that all firmware settings remain correct after power outages. Because the 150-F43NCD includes an integrated bypass, the contactor experiences less wear, reducing maintenance frequency and cost. This reliability translates into reduced downtime and a lower total cost of ownership.
Selection Guide & Purchasing Advice
Before purchasing, confirm that the 150-F43NCD matches your motor's full-load current and horsepower requirements. Check the input voltage and phase configuration. For additional support, consult the SMC-Flex user manual. PLC Source PRO offers genuine Allen-Bradley 150-F43NCD units with fast shipping and responsive customer service. Ensure you order the correct part number to avoid delays.
