Product Overview
When industrial processes demand smooth motor starts and reliable protection, the Allen-Bradley 150-F317FHD SMC-Flex Softstarter delivers. This solid state controller provides advanced motor control for a wide range of manufacturing and processing applications. With a robust IP65 (Type 4/12) enclosure, the 150-F317FHD withstands harsh environments while maintaining precise operation.
Part of the SMC-Flex product line, the 150-F317FHD is engineered to reduce mechanical stress on AC induction motors, extending equipment life and minimizing downtime. Its compact design and cost-effective build make it a practical choice for modern automation systems.
Technical Specifications
The Allen-Bradley 150-F317FHD offers performance metrics that meet demanding industrial requirements. Key parameters include:
| Specification |
Value |
| Manufacturer |
Allen Bradley |
| Category |
Drives |
| Product Line |
SMC-Flex |
| Part Number |
150-F317FHD |
| Weight |
32.00 lbs (14.51 kg) |
| Bulletin Number |
Solid State Controller |
| Enclosure Type |
IP65 (Type 4/12) |
| Controller Rating |
317 A, 250 Hp @ 460V AC |
| Input Line Voltage |
200-208V AC, 3-phase, 50 and 60 Hz |
| Control Voltage |
100-240V AC (5-480 A units) |
| Rated Voltage |
200/208V AC |
These specifications ensure the 150-F317FHD integrates seamlessly into 200-208V AC systems, delivering reliable performance across various industrial settings.
Industry Applications
The Allen-Bradley 150-F317FHD excels in applications requiring controlled acceleration and deceleration of motors. Typical use cases include:
-
Conveyor Systems: Smooth starting reduces belt stress and product spillage.
-
Pumps and Fans: Prevents water hammer and mechanical shock, extending pump life.
-
Compressors: Limits inrush current, protecting electrical components.
In each scenario, the 150-F317FHD minimizes mechanical damage, directly contributing to lower maintenance costs and improved operational efficiency.
Installation & Setup Guidance
Proper installation is critical for maximizing the performance of the 150-F317FHD. Follow these practical steps:
- Mount the unit in a clean, dry location that meets the IP65 enclosure requirements for protection against dust and water jets.
- Verify that the input line voltage matches the 200-208V AC, 3-phase, 50/60 Hz rating before energizing.
- Ensure adequate airflow around the enclosure to prevent overheating, even though the IP65 design offers robust protection.
- Connect control wiring according to the provided terminal diagrams, using the 100-240V AC control voltage range (for 5-480 A units).
- After installation, perform a functional test to confirm motor control and protection settings are correctly configured.
Maintenance & Reliability
Routine maintenance enhances the longevity of the 150-F317FHD and reduces total cost of ownership. Inspect the unit periodically for dust accumulation, loose connections, or signs of moisture ingress. Because the enclosure is rated IP65, it resists many environmental contaminants, but regular checks ensure optimal performance. The solid state design eliminates mechanical wear in the switching components, minimizing maintenance frequency. By investing in preventive care, you avoid unplanned downtime and extend the service life of your motor control system.
Selection Guide & Purchasing Advice
Before purchasing the Allen-Bradley 150-F317FHD, verify that the controller rating (317 A, 250 HP @ 460V AC) and input voltage (200-208V AC, 3-phase) match your motor and power supply requirements. Confirm the enclosure type (IP65) suits your installation environment. For additional support and genuine product sourcing, PLC Source PRO offers reliable industrial automation components and can assist with your selection. Ensure you review the control voltage compatibility (100-240V AC) for your application.
