Product Overview
The Bently Nevada BA42608-11-02 is an IP65 water and dust-resistant velocity transducer housing designed for demanding industrial environments. This housing protects velocity sensors while maintaining reliable vibration monitoring performance. When used with 9200 or 74712 velocity sensors, the sensors must have ATEX or Multiple approvals and an isolator with 5/8-in 18 UNF-2B male threads and a top mount terminal strip.
This model features an unthreaded base with a 28.5 mm (1.125 in) diameter and tall cap, plus a 1/2-in NPT explosion-proof cable exit fitting. The BA42608-11-02 delivers robust protection against moisture and corrosion, making it suitable for harsh industrial settings.
Technical Specifications
The following table outlines the key specifications for the BA42608-11-02:
| Parameter |
Value |
| Outlet Port Size |
1/2-in NPT |
| Internal Mounting Thread (BA42608) |
5/8-in 18 UNF-2B |
| Weight |
1.6 kg (3.55 lb) without velocity sensor or fittings |
| Temperature Rating |
-29°C to +121°C (-20°F to +250°F) |
| Moisture Resistance |
Resistant to moisture and corrosion but not submersible |
| O-ring Material |
Neoprene |
| Compliance |
RoHS Directive 2011/65/EU |
Industry Applications
The BA42608-11-02 excels in applications where vibration monitoring is critical and environmental protection is essential. Typical use cases include:
-
Rotating Machinery Monitoring: Ideal for motors, pumps, and compressors in dusty or wet environments.
-
Process Industries: Suitable for chemical, petrochemical, and pharmaceutical plants where moisture and corrosion are concerns.
-
Oil & Gas Facilities: Provides reliable protection in offshore and onshore installations with harsh conditions.
For example, in a water treatment plant, the IP65 rating ensures the housing withstands high humidity and occasional washdowns, maintaining accurate vibration readings without downtime.
Installation & Setup Guidance
Proper installation is crucial for optimal performance. Follow these guidelines:
- Mount the housing on a flat, clean surface using the unthreaded base. Ensure the base diameter (28.5 mm) aligns correctly with the mounting bracket.
- For velocity sensors with 5/8-in 18 UNF-2B threads, use an isolator with matching male threads and a top mount terminal strip as specified.
- Tighten the cable exit fitting (1/2-in NPT) securely to maintain explosion-proof integrity.
- Verify the O-ring (neoprene) is properly seated to maintain the IP65 seal.
Maintenance & Reliability
The BA42608-11-02 requires minimal maintenance due to its robust construction. However, regular inspections are recommended:
- Periodically check the O-ring for wear or damage and replace if necessary.
- Inspect the cable fitting and ensure it remains tight to prevent moisture ingress.
- Clean the housing exterior with a mild detergent if exposed to corrosive substances.
By following these simple steps, you extend the service life of the housing and avoid costly replacements, maximizing your return on investment.
Selection Guide & Purchasing Advice
Before purchasing, verify the following to ensure compatibility:
- Confirm your velocity sensor model (e.g., 9200 or 74712) and its required mounting thread. The BA42608-11-02 uses a 5/8-in 18 UNF-2B internal thread.
- Check the outlet port requirement: this model includes a 1/2-in NPT fitting.
- Ensure the operating temperature range (-29°C to +121°C) meets your site conditions.
PLC Source PRO offers this genuine Bently Nevada BA42608-11-02 with factory warranty and original packaging. Contact our team for bulk pricing or expedited shipping options.
