Product Overview
The Allen-Bradley 1762-OX6I is a discrete output module from the MicroLogix 1200 series. It delivers six individually isolated Form C relay outputs, making it ideal for switching diverse loads in industrial control systems. Whether you are managing motors, solenoids, or indicator lights, this module provides reliable, isolated switching for your automation needs.
With a compact design and straightforward installation, the 1762-OX6I integrates seamlessly into existing MicroLogix control architectures, offering a cost-effective expansion path for your I/O requirements.
Technical Specifications
| Specification |
Detail |
| Part Number |
1762-OX6I |
| Brand |
Allen-Bradley |
| Product Family |
MicroLogix 1200 |
| Product Type |
Discrete Output Module |
| Output Form |
Type C Relay |
| Number of Outputs |
6 (individually isolated) |
| Output Voltage Range |
5-125VDC and 120/240VAC |
| Signal Delay (ON) |
10 ms |
| Signal Delay (OFF) |
20 ms |
| Bus Current Draw (max) |
110 mA at 5V DC, 110 mA at 24V DC |
| Dimensions (H x W x D) |
90 x 40.4 x 87 mm (3.54 x 1.59 x 3.43 in.) |
| Mounting Type |
DIN Rail |
Key Features & Benefits
-
Individually Isolated Outputs: Each of the six relay outputs is isolated, allowing different loads with separate reference potentials to be switched safely.
-
Form C Relay Contacts: Provides both normally open (NO) and normally closed (NC) terminals per output, offering flexibility in control logic.
-
Wide Voltage Compatibility: Handles both AC and DC loads across a broad range, simplifying inventory and installation.
-
Fast Switching: With a maximum ON delay of 10 ms and OFF delay of 20 ms, the module responds quickly to control commands.
-
DIN Rail Mounting: Simplifies panel installation and reduces downtime during setup.
Applications
The Allen-Bradley 1762-OX6I is well-suited for a variety of industrial applications, including:
-
Material Handling: Controlling conveyor motors and actuators with isolated relay outputs to prevent electrical interference.
-
Packaging Machinery: Switching solenoids and pneumatic valves in high-cycle packaging lines, where reliable switching is critical.
-
Process Control: Activating alarms, pilot lights, and small pumps in chemical or food processing plants.
Installation & Setup
Mount the 1762-OX6I on a standard DIN rail. Ensure at least 2 inches of clearance on all sides for proper airflow and heat dissipation. Connect the module to the controller using the provided flat ribbon cable with a female bus connector. Secure the module with end anchors to prevent movement in high-vibration environments. For extreme vibration, use two panhead screws for additional stability.
Compatibility & Integration
This module is compatible with MicroLogix 1100, MicroLogix 1200, and MicroLogix 1400 controllers. It can be installed in multiple quantities: up to 4 modules with a MicroLogix 1100, 6 with a MicroLogix 1200, and 7 with a MicroLogix 1400. The 1762-OX6I communicates with the controller via the backplane, requiring no additional wiring.
Maintenance & Reliability
Regularly inspect the relay contacts for signs of wear, especially in high-cycle applications. Keep the module free of dust and debris to maintain optimal thermal performance. The module operates reliably in temperatures from 0 to 55°C and at altitudes up to 2000 meters, making it suitable for most industrial environments.
Buying Guide
When purchasing the Allen-Bradley 1762-OX6I, verify the part number and compatibility with your existing controller. Consider the number of outputs required and the load types you need to switch. PLC Source PRO offers genuine Allen-Bradley modules with fast shipping and competitive pricing, ensuring you get the right part for your system.
