Product Overview
The Allen-Bradley 150-F25FAD is a solid state controller from the SMC-Flex product line, engineered for reliable motor starting and stopping in demanding industrial environments. With its IP65 (Type 4/12) enclosure, this unit is built to withstand dust, water spray, and harsh conditions, making it a robust choice for a wide range of applications.
This controller is rated at 25 A and supports motors up to 15 Hp at 460V AC. It operates on a 230V AC, 3-phase input line at both 50 and 60 Hz, offering flexibility for global installations. The control voltage is 100-240V AC, compatible with standard control systems.
Technical Specifications
| Specification |
Value |
| Manufacturer |
Allen-Bradley |
| Product Line |
SMC-Flex |
| Part Number |
150-F25FAD |
| Weight |
225.00 lbs (102.06 kg) |
| Enclosure Type |
IP65 (Type 4/12) |
| Controller Rating |
25 A, 15 Hp @ 460V AC |
| Input Line Voltage |
230V AC, 3-phase, 50 and 60 Hz |
| Control Voltage |
100-240V AC (5-480 A units) |
| Rated Voltage |
230V AC |
Industry Applications
The Allen-Bradley 150-F25FAD is ideal for controlling three-phase AC motors in pumps, fans, conveyors, and compressors. Its IP65 enclosure permits installation in washdown areas or dusty environments without additional protection. For example, in a food processing plant, this controller can manage a 15 Hp conveyor motor while resisting frequent high-pressure cleaning.
In HVAC systems, the 150-F25FAD ensures smooth acceleration of large fans, reducing mechanical stress and extending equipment life. Its 50/60 Hz rating makes it suitable for international projects.
Installation & Setup Guidance
When installing the 150-F25FAD, ensure the mounting surface is flat and capable of supporting its 225 lb weight. Provide adequate clearance for ventilation and cable entry. Connect the 230V AC three-phase input line to the designated terminals, and wire the motor to the output terminals per the wiring diagram. Set the control voltage to match your system (100-240V AC). Always follow local electrical codes and use proper torque for terminal connections.
Maintenance & Reliability
Routine inspection of the 150-F25FAD should include checking for loose connections, signs of overheating, and accumulation of dirt or moisture on the enclosure. The IP65 rating reduces maintenance frequency, but periodic checks every six months are recommended. Keep the enclosure sealed to maintain its protective rating. Proper maintenance ensures long service life and minimizes downtime.
Compatibility & Integration
The 150-F25FAD is part of the Allen-Bradley SMC-Flex family, designed to integrate seamlessly with existing motor control centers and PLC systems. It accepts standard control signals and can be used with external pilot devices. While it does not include built-in network communication, it can be controlled via hardwired inputs, making it compatible with most industrial control architectures.
Buying Guide
Before purchasing the Allen-Bradley 150-F25FAD, verify that your motor's full-load current does not exceed 25 A and that your supply voltage matches the 230V AC rating. Confirm the enclosure size fits your installation space. PLC Source PRO offers genuine Allen-Bradley parts with fast shipping, ensuring you get reliable components for your operations.
