Product Overview

The GE IC200ALG266 is a 15-point analog voltage input module from the VersaMax I/O series, originally by GE Intelligent Platforms and now under Emerson Automation. This module interfaces with analog sensors and feedback devices that generate signals from -10 VDC to +10 VDC. With 15 single-ended input channels, it provides a resolution of 15 bits and a maximum update rate of 7.5 ms, making it suitable for precision measurements in industrial automation.

Key Specifications

The GE IC200ALG266 operates on a backplane power supply and draws a maximum current of 150 mA from the 5 VDC source. It requires no external supply for the input channels. Each channel has an input impedance of 100 k ohms and a filter response of 32 Hz ±20%. The module offers a typical accuracy of 0.3% of full scale at 25°C, with a maximum of 1% at 60°C. The analog-to-digital conversion provides a digital resolution of 0.3125 mV per count.

Compatibility and Integration

This module integrates into a single slot of a VersaMax backplane and supports one group of 15 channels. It features an OK LED that indicates proper configuration and operational status. The IC200ALG266 includes software-configurable input states for CPU stop or module errors, allowing users to choose between default or last state operation for safe startup after power interruptions.

Diagnostics and Safety Features

Built-in diagnostics monitor for loss of internal power and A/D conversion errors. The module detects faults when the converter output exceeds 6% of full scale, reporting errors to the CPU. Human Machine Interface (HMI) and SCADA systems can display these faults for quick intervention. Additionally, the module provides overvoltage protection up to 30 VDC and ensures that a fault on one channel does not affect the others. The isolation rating is 250 VAC continuous and 1500 VAC for one minute.

Practical Applications

Engineers use the GE IC200ALG266 in distributed I/O architectures to connect analog instruments like pressure transmitters, temperature sensors, and flow meters. Its high resolution and fast update rate support precise monitoring and control in manufacturing processes. The module's ability to handle radiofrequency interference derating of up to ±2% ensures reliable operation in industrial environments.

Overall, the GE IC200ALG266 delivers robust performance for analog voltage input tasks, with features that simplify integration and maintenance. Automation professionals seeking a dependable, high-resolution input module will find this component a valuable addition to their systems.
