Schneider BMXP342020 Processor Module: A Technical Overview
The Schneider BMXP342020 is a processor module designed for the Modicon M340 automation platform. It handles up to 1024 discrete I/O and 256 analog I/O in multi-rack configurations. Engineers rely on this module for its robust communication options and fast processing capabilities.
Key Specifications
This module supports four racks and eleven slots. It offers a discrete I/O capacity of 1024 points for multi-rack setups and 704 for single-rack configurations. Analog I/O capacity reaches 256 points for multi-rack and 66 for single-rack. Additionally, it supports 36 application-specific channels.
Communication Capabilities
The BMXP342020 includes an integrated Ethernet TCP/IP port with 10/100 Mbit/s speed. It also features non-isolated serial links for Modbus and character mode communication. These serial links support RS232C and RS485 with baud rates from 0.3 to 19.2 kbit/s. The module can connect up to two Ethernet communication modules and four AS-Interface modules.
For embedded services, it provides bandwidth management, Modbus TCP messaging, and SNMP network administration. The Ethernet port supports 10BASE-T/100BASE-TX, and the device handles up to 32 devices per segment for character mode and Modbus.
Performance and Memory
The processor executes Boolean instructions in 0.12 µs and floating-point operations in 1.16 µs. It delivers 8.1 K instructions per ms for 100% Boolean tasks. The module comes with a pre-installed memory card (BMXRMS008MP) for backup and can activate a standard web server. Internal memory includes 4096 kB total, with 256 kB for data and 3584 kB for programs and constants.
The application structure supports one cyclic/periodic master task, one periodic fast task, and up to 64 event tasks. System overhead is 0.13 ms for fast tasks and 0.7 ms for master tasks.
Why Choose the Schneider BMXP342020?
This processor module suits applications requiring reliable communication and fast logic execution. Its support for multiple I/O types and network protocols makes it versatile for industrial automation. The module operates within 32 to 140 °F and requires a 24 V DC supply with 95 mA current consumption. For more details, visit PLC Source PRO for pricing and availability.
