Product Overview
The Allen-Bradley 150-F361NCD is a solid-state smart motor controller from the SMC-Flex product line, engineered for precise control of three-phase squirrel cage induction motors. With a robust 361 A rating and 300 Hp at 460V AC, this open-enclosure module delivers reliable performance in demanding industrial environments.
Key Technical Specifications
| Parameter |
Value |
| Manufacturer |
Allen-Bradley |
| Category |
Drives |
| Product Line |
SMC-Flex |
| Part Number |
150-F361NCD |
| Weight |
87.00 lbs (39.46 kg) |
| Bulletin Number |
Solid State Controller |
| Enclosure Type |
Open |
| Controller Rating |
361 A, 300 Hp @ 460V AC |
| Input Line Voltage |
200-575V AC, 3-phase, 50 and 60 Hz |
| Control Voltage |
100-240V AC (5-480 A units) |
| Rated Voltage |
500/575V AC |
Performance and Control Features
The 150-F361NCD uses microprocessor control to manage motor starting and stopping. It supports standard three-phase squirrel cage induction motors and Wye-Delta (6-lead) motors. Seven standard start modes are available for controlling resistive loads, including soft start, linear speed acceleration, torque control start, current limit start, and selectable kickstart.
This controller includes an LCD with a programmable keyboard, making configuration and monitoring straightforward in industrial settings. Inbuilt electronic motor overload protection, along with SCR or Run bypass features, enhances motor safety and system reliability.
Applications
The 150-F361NCD is ideal for applications requiring smooth, controlled motor starting and stopping. Common uses include conveyors, pumps, fans, compressors, and other heavy industrial machinery. Its wide input voltage range (200-575V AC) and high current rating make it suitable for large motors in manufacturing plants, water treatment facilities, and process industries.
Installation and Setup
As an open-enclosure unit, the 150-F361NCD is designed for installation in a suitable electrical cabinet or panel. Ensure proper ventilation and adequate clearance for heat dissipation. Follow the manufacturer's wiring diagrams and torque specifications for all connections. The programmable keyboard allows quick setup of start modes and parameters.
Maintenance and Reliability
Regular inspection of the controller's cooling fans, if present, and cleaning of dust from the enclosure are recommended to maintain optimal performance. Check all electrical connections periodically for tightness. The solid-state design reduces mechanical wear, contributing to long service life and minimal downtime.
Selection Guide
Before purchasing, verify that the 150-F361NCD matches your motor's voltage, current, and horsepower requirements. Confirm the enclosure type meets your installation environment. For additional technical support or to place an order, contact PLC Source PRO, your trusted supplier of industrial automation spare parts.
